Display
Panel Technology: IPS with Direct LED backlights
Active Screen Area (W x H) [mm]: 1,073.8 x 604
Screen Size [inch/cm]: 48.5 / 123.2
Aspect Ratio: 16:9
Pixel Pitch [mm]: 0.280
Brightness [cd/m²]: 400
Contrast Ratio (typ.): 1200:1
Viewing Angle [°}: 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Colour Depth [bn}: 1.073 (10bit)
Response Time (typ.) [ms}: 8
Panel Refresh Rate [Hz]: 60
Haze Level [%]: Standard (1)
Supported Orientation: Landscape; Portrait
Resolution
Native Resolution : 3840 x 2160
Supported Resolutions
1280 x 720;
1920 x 1080;
1920 x 1200;
3840 x 2160;
4096 x 2160;
640 x 480;
720 x 480;
720 x 576
Synchronisation Rate
Horizontal Frequency [kHz] 15 - 136
Vertical Frequency [Hz] 24 - 75
Connectivity
Input Video Analogue 1 x VGA; Component (RCA); Composite (RCA)
Input Video Digital 3 x HDMI
Input Audio Analogue 1 x 3,5 mm jack
Input Audio Digital 3 x HDMI
Input Control LAN 100Mbit; RS232
Input Data 1 x USB 2.0 (MediaPlayer); 1 x USB Typ-C (5V/3A, power for external devices)
Output Audio Analogue 1 x 3,5 mm jack
Output Audio Digital 1 x SPDIF
Remote Control Remote Control IR; RS-232C (9-pin D-sub) Input
Sensors
Ambient Light Sensor Integrated, triggered actions programmable
Temperature Sensor Integrated, 1 sensors, triggered actions programmable
Mechanical
Dimensions (W x H x D) [mm] Without stand: 1,102.8 x 634 x 71.6
Weight [kg] Without stand: 12.4
Bezel Width [mm] 12.5 (left, right and top); 13.9 (bottom)
VESA Mounting [mm] 4 holes; 400 x 200 (FDMI); M6
MediaPlayer
Supported File Storage / File System USB 2.0 / FAT16, FAT32
Supported Image Formats JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
Supported Video Formats MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10 Pro)
Supported Audio Formats MP3 (MP3); max. bit-rate 320 kBit/s
